2900 Series – 3 Piece, Vee Port, Sanitary, Tube OD, Control Ball Valve (Engineered in USA)

Size:

1/4” through 4”

Pressure Rating:

Up to 1500 WOG

Ends:

Extended Tube OD, Short Tube OD, Clamp Ends, Compression Fitting (AVCO-LOK), Vacuum Fitting

Body Materials:

316L Stainless Steel, Various Alloys

Ball & Stem Materials:

316L Stainless Steel, Various Alloys

Seat Materials:

TFM, PEEK, UHMWPE, Cavity Filled

Standards:

ASME BPE, ISO 5211

Category:

Description

The AVCO 2900 series V-ported (Vee) flow control ball valve brings together all the advantages of the 2100 series 3-piece sanitary ball valve into the precision flow control market. Precise control is achieved by an engineered Vee or slot in the floating ball along with tight tolerances to minimize hysteresis (backlash and judder). Standard balls are available with 15, 30, 45, 60 and 90 degree Vee ports. We also carry blanks that are engineered to suit custom flow characteristics. The 2900 series V-port valve also facilitates tight shut-off to act as isolation when needed. The Vee balls can also be used in our 2500 series cryogenic valves where precise control is needed in cryogenic service. When coupled with an actuator and positioner via the ISO 5211 mount pad, these valves give truly accurate, reliable and responsive flow. As part of the 2000 series, the ball valve is designed to meet ASME BPE and comes with all the same options such as cavity filled seats, purge ports and electropolished finish.
